| 전압: | 220V/380V | 힘: | 45kW |
|---|---|---|---|
| 차원: | 2030*1960*1530mm | 무게: | 5500kg |
| 설정 속도: | 1550개 Ｒ / 분 | 드럼 직경: | 800mm |
| 드럼 길이: | 450mm | 드럼 크기: | 100L |
| 로딩 용량: | 150kg | 최대 분리 계수: | 1070 |
| 모터 파워: | 45kW | 용량: | 0.8-2.5t/h |
| 수분: | 5-35% | 고체상 손실: | 0.05% |
| 핵심 구성 요소: | plc, 베어링, 모터 | ||
| 강조하다: | 45kw Power Peeler Centrifuge,100L Capacity Continuous Centrifuge Separator,1550 Setting Speed Siphonic Centrifuge |
||
| Item/Type | GKH800-N | GKH1250-N | GKH1600-N |
|---|---|---|---|
| Drum diameter (mm) | 800 | 1250 | 1600 |
| Drum length (mm) | 450 | 600 | 1000 |
| Drum volume (L) | 100 | 355 | 830 |
| Loading capacity (Kg) | 150 | 450 | 996 |
| Drum speed (r/min) | 1550 | 1200 | 950 |
| Maximum separation factor | 1070 | 1006 | 799 |
| Motor power (Kw) | 45 | 90 | 132 |
| Size (mm) | 2030×1960×1530 | 2685×2300×1900 | 4050×2745×2295 |
| Weight (Kg) | 5500 | 10500 | 16550 |
| Model | Capacity (wet base) T/h | Moisture % | Solid phase loss % |
|---|---|---|---|
| GKH800N | 0.8-2.5 | 5-35 | 0.05 |
| GKH1250 | 3.5-6.5 | 5-35 | 0.05 |
| GKH1600 | 6.5-10 | 5-35 | 0.05 |
| Packaging Specifications | Details |
|---|---|
| Size | 123 (L) × 456 (W) × 789 (D) |
| Weight | 1.2 T |
| Packaging Details | Standard wooden box packaging. European exports include fumigation. Alternative packaging (PE film) available for tight containers or special requests. |
